Meyer parts by assembly
Meyer centering bell parts
Centering bells and devices line each bottle neck up under its filling valve so the sealing rubber seats squarely. Below are the parts that appear across our Meyer manuals, and where to find each version by filler.
What wears
- Centering bells and cups
- Centering rods and guide bushings
- Springs
- Uplift cams
Common Meyer centering bell parts
Parts that appear in two or more of our Meyer manuals. Ask us to confirm fit for your machine.
| Part number | Description | Manuals | |
|---|---|---|---|
| 102-00671020067 | Bolt, hex head | 7 | Request |
| 133-68151336815 | Strap, centering bell family | 4 | Request |
| 102-03871020387 | Washer, lock | 4 | Request |
| 135-19451351945 | Spring, centering device | 3 | Request |
| 1004030 | O-ring | 3 | Request |
| 135-94221359422 | Bushing, centering bell | 3 | Request |
| 135-1227 | Support, bushing bell | 2 | Ask us |
| 1370980 | Spring, centering bell | 2 | Request |
| 101-24851012485 | Pin, groove | 2 | Request |
| 133-1680 | Strap | 2 | Ask us |
| 137-17421371742 | Cup, centering | 2 | Request |
| 136-05581360558-1-FCI | Rod, guide centering bell retro-fit | 2 | Request |
| 70275-DL70275DL | Centering, bell assembly | 2 | Request |
| 104-71731047173 | Spring, centering bell | 2 | Request |
Find it in your filler's manual
- Meyer 32/40/48 valve filler: Centering Bell 5 parts
- Meyer 52-12 filler: Centering Bell & Rod Assembly 10 parts
- Meyer A-Model filler: Centering Bell 6 parts
- Meyer Tri-Star filler: Centering Bell and Rod Assembly 11 parts
- Meyer Concept III filler: Centering Bell Assembly 5 parts
- Meyer 65-15 filler: Centering Bell Assembly 9 parts
- Meyer 65-15 filler: Centering Bell Rod Assembly 7 parts
- Meyer Remanufactured filler: Centering Bell 13 parts
Need Meyer centering bell parts?
Send the machine model, serial number and a photo and we will identify the part.
